Dana 2-4-533 Spicer Drive Shaft End Yoke

by Dana

MPN: 2-4-533
SKU: 2-4-533-S03-745

Sold out

$64.29 - $64.29

$64.29

$64.41

$64.41 - $64.41

$64.41

Warehouse: Calgary-A

This product is held in stock at the Calgary-A warehouse. Shipping & pick-up available.

Order within 8h 16m and pick up today after 2 p.m.

5935 35 St SE, Bay #15, Calgary, AB, T2C 2H1, Canada

Availability:

Out of stock

Genuine OE quality. Tested and proven.; Built to meet OE standards set by Dana; Tested and validated to rigorous OE specifications; Latest production upgrades ensure genuine Spicer parts are as good or better than the OE parts they replace C/L To End Hub S:2.562 IN; Hole Diameter (In) P:1.250 IN; Hole Diameter - Max:1.251 IN; Hole Diameter - Min:1.250 IN; Hub Diameter R:2.125 IN; Involute Spline:N; Joint Angle No.1:17; Keyway Location W:12; Keyway Width - Max:0.3155 IN; Keyway Width - Min:0.3135 IN; Material:Steel; Outside Yoke Dimension (In) E:3.469 IN; Sae Keyway Width (In) X:0.312 IN; Series:1310; Set Screw Hole Diameter (In):0.375 IN; Set Screw Location W:6; Type:Straight Round Hole; Yoke Bearing Dimension (In) D:1.062 IN; Yoke Style:SR.

1310 Series Straight Round Hole Yoke - Not Vehicle Specific = No Applications = No Appliction Data

MPN: 2-4-533
