Dana 2-4-523 Spicer Drive Shaft End Yoke

by Dana

MPN: 2-4-523
SKU: 2-4-523-S03-745

$277.07 - $277.07

$277.07

$277.62

$277.62 - $277.62

$277.62

Warehouse: Calgary-A

This product is held in stock at the Calgary-A warehouse. Shipping & pick-up available.

Order within 8h 16m and pick up today after 2 p.m.

5935 35 St SE, Bay #15, Calgary, AB, T2C 2H1, Canada

Availability:

Only 1 left!

Spicer Drive Shaft End Yoke

C/L To End Hub S:2.562 IN; Hole Diameter (In) P:1.125 IN; Hole Diameter - Max:1.1255 IN; Hole Diameter - Min:1.1245 IN; Hub Diameter R:2.125 IN; Involute Spline:N; Joint Angle No.1:17; Keyway Location W:12; Keyway Width - Max:0.3155 IN; Keyway Width - Min:0.3135 IN; Material:Steel; Outside Yoke Dimension (In) E:3.469 IN; Sae Keyway Width (In) X:0.312 IN; Series:1310; Set Screw Hole Diameter (In):0.375 IN; Set Screw Location W:6; Type:Straight Round Hole; Yoke Bearing Dimension (In) D:1.062 IN; Yoke Style:SR.

MPN: 2-4-523
